SA6011T ANALYSUER DE SPECTRE 1GHz + GENERATEUR SUIVEUR

د.ج 265.000,00

Disponibilité: in stock

Comparer
Ajouter à la liste d’envies
Category:

Description

Spectrum Analyzer
Model: SA6010 / SA6011T

Categories: , , , .
Feature.
.Frequency range: 0.15~1050MHz
.Amplitude range: -100~+13dBm
.Tracking generator (SA6011T)
.Output level range: -50~+1dBm
(in 10dB steps and var.)
Technical data SA6010/SA6011T
Frequency range 0.15~1050MHz
CF adjust range 0~1050MHz
Resolution of frequency display 10kHz
RBW 400kHz and 20kHz
Video filter bandwidth 4kHz
Average noise level 190dBm (20kHz bandwidth)
Amplitude range -100dBm to + 13dBm
Sweep rate 40Hz
Reference level -27dBm to +13dBm
Frequency generator TCXO DDS
Input attenuator accuracy ±2dB/10dB
Signal input connector N type
Stability ±10ppm/year
Aging ±2ppm/year
Accuracy ±10kHz
Display CRT 8x10Div
Third order intermod -90dBc (two signals>3MHz apart)
Scan width 100kHz/div~100MHz/div, 1-2-5 steps and 0 step
Log scale fidelity ±2dB (CF: 500MHz 10dBm attn zero scan RBW: 400kHz) 500Hz
Dimensions(W×H×D) 285mmx125mmx380mm
Weight 5.2kg (SA 6010), 5.6kg (SA6011T)
Tracking Generator(SA6011T)
Output Frequency 0.15~1050Mhz
Output attenuator accuracy ±2dB
Output attenuator 0~40dB(4×10dB steps)
Frequency response ±1.5dB
Output impedance 50Ω(BNC)
Radio Frequency Interference(RFI) <20dB
Output level range -50dBm to +1dBm (in 10dB steps and Var.)
Options SA-RTB-1 reflection bridge
