SPECIFICATIONS
Warranty:
Δεν καλύπτεται με εγγύση απο τον Κατασκευαστή
Company:
DFROBOT
Part Number:
FIT0277
Gross Weight:
0.1kg
Made in:
China
Voltage (Range):
12Volt
Current (Stall):
3.6A
Speed:
143RPM
Torque:
5.5kg.cm
Gearmotor Style:
Precision Spur
Gear Material:
Metal
Gearbox Ratio:
- 56:1
Encoder:
Yes
EXTRA SPECS
- Model: 28PA51G
- Working voltage: 12V
- No load RPM (before gearbox): 8000±10% rpm
- No load 68dBA ( 10cm measurement distance )
- Gear ratio: 56:1
- No load RPM (after gearbox): 143±10% rpm@12V
- No load current: @ 12V: 0.39A
- Stall current: 3.6A
- Rated torque @ 12V: 5.5kgf.cm (79oz.in)
- Encoder Resolution: 13 PPR (663 PPR for gearbox shaft)
- Two phase hall encoder
- Size: 123x36x36mm
- Weight: 270g
