FEATURES :
- Companion to a DMM for measuring up to 200 A AC
- 1 mA per Amp output guarantees easy reading on you meter
- Take accurate current readings without breaking the circuit
- Max. conductor Ø 20 mm
- CAT III 600 V safety rating
Specifications
Nominal current range 200 A Continuous current range 0.5 A – 200 A Maximum non-destructive 240 A Lowest measurable current 0.5 A Basic accuracy 1% + 0.5 A
(48-65 Hz)
(% reading + floorspec)Useable frequency 40 Hz – 10 kHz Output level(s) 1 mA/A Safety Specifications Safety CAT III, 600 V Maximum voltage 600 V AC Mechanical and General Specifications Warranty 1 year Maximum conductor diameter 20 mm Maximum conductor size (busbar) 20 x 5 mm Output cable length 1.5 m Shrouded banana plugs Yes
