SPECIFICATION
|
Manufacturer
|
OWON | |
|
Type of meter
|
benchtop multimeter | |
|
Kind of display used
|
LCD 4,5″ | |
|
Display resolution
|
480×320 | |
|
Sampling
|
65x/s | |
|
DC voltage measuring range
|
50mV/500mV/5V/50V/500V/1kV | |
|
DC voltage measuring accuracy
|
±(0.025% + 5% range) | |
|
AC voltage measuring range
|
500mV…750V | |
|
AC voltage measuring accuracy
|
±(0.5% + 30% range) | |
|
AC current measuring range(1) indirect measurement)
1) indirect measurement
|
500µA/0.5A/5A/10A | |
|
DC current measuring range
|
0.5mA/5mA/50mA/500mA/5A/10A | |
|
DC current measuring accuracy
|
±(0.15% + 20% range) | |
|
AC current measuring accuracy
|
±(0.5% + 20% range) | |
|
True effective value measurement
|
True RMS AC | |
|
Resistance measuring range
|
500Ω/5kΩ/50kΩ/500kΩ/5MΩ/50MΩ | |
|
Resistance measuring accuracy
|
±(0.1%+5% range) | |
|
Capacitance measuring range
|
50nF…50mF | |
|
Capacitance measuring accuracy
|
±(2.5%+ 5% range) | |
|
Frequency measuring range
|
10…60MHz | |
|
Frequency measuring accuracy
|
±(0.2% + 8% range) | |
|
Diode test
|
3V | |
|
Continuity test
|
<1kΩ | |
|
Measurement
|
AC current, AC voltage, capacitance, continuity, DC current, DC voltage, frequency, resistance (2-wire), resistance (4-wire), temperature | |
|
Interface
|
RS232 | |
|
Conform to the norm
|
CAT II 600V CAT II 1000V EN 61010 | |
|
Dimensions (W x H x D)
|
235x110x295mm | |
|
Display parameters
|
5,5 digit |
