Specifocation :
- 200MHz Bandwidth，1GS/s sample rate
- 14-bit high resolution ADC
- 40M record length max 70,000 wfms/s waveform refresh rate
- low back ground noise
- 8 inch 800 x 600 high resolution LCD, optional multi-touch screen, more user-friendly operation experience
- SCPI, and LabVIEW supported
- multi- trigger, and bus decoding function
- multi-interface integration – USB host, USB device, USB port for PictBridge, LAN, AUX, and VGA
| Model | XDS3204AE |
|---|---|
| Sample rate | 1 GSa/s |
| Geheugen diepte | 40 MPts |
| Waveform capture rate | tot 70 000 Wfm/s |
| Kanalen | 4 |
| Horizontale schaal | 2 ns/div – 1000s/div |
| Verticale resolutie | 1 mV/div – 10 V/div |
| Decodeermogelijkheden (gratis vanuit fabriek geïnstalleerd) | IIC, SPI, RS232, CAN |
| Maximale spanning | 200V RMS |
| Ingangsimpedantie | 1 MΩ en 15 pF |
| Display | 8″ LCD, 800×600 pixels, Touchscreen |
| Gewicht | 2.6 kg |
| Afmetingen | 340 x 177 x 90 mm |
Inlcuded Accessories :
1 x XDS3204AE Oscilloscope
1 x 220V Power cord
1 x CD ROM
1 x Quick start guide
1 x USB Cable
4 x Probes
